DOOR FRAME SYSTEM
The door frame system is perfect for clients working with small spaces and for clients reluctant to conduct disassembly of existing layouts during renovations of older buildings. With the help of concrete blocks already in place, doors and their corresponding frames are installed, yielding a stunning transformation that will certainly captivate anyone who lays eyes on the resulting washroom cubicle system.
Isometric Plan
Specification Options
|
Overall Height |
1800mm |
|
Colors |
Refer to the ADLER Color Range |
|
Floor Mounting Options |
N/A |
|
Headrail and Profiles |
Aluminum in Brushed S/S effect |
|
Floor to Door Clearance |
200mm |
|
Tailored to Spec |
|
|
Fittings |
Stainless Steel 304 |
|
Door – Toprail Clearance |
No Toprail |
|
Panel Size |
1830mm x 1830mm |
|
Ceiling Clearance |
Variable |
|
Board Material |
Compact Laminate 12mm Thick |
* Special Panel Size – Indent Order
** Option to Upgrade Accessories
*** Min. door to ceiling clearance for floor to ceiling systems
